use:
ITE Shells
In-Ear-Monitoring
Hearing Protection (passive and solid)
Properties:
Low viscosity,High initial hardness, Max building speed,Max construction precision, Very high surface hardness, Strong depth curing ,Reduced sedimentation tendency
UV curing premium resin (wavelength 385 nm) for generative manufacturing of hard ITE shells. Markedly lower viscosity than conventional materials (=> reduced loss of material, easier cleaning). Maximum construction safety, even for finest support structures, due to high initial hardness. Very high mechanical flexural strength and fracture resistance, without being brittle. Accelerated throughput by short light exposure times. Biocompatible & Bisphenol A free.
Class IIa, standard colours: clear, rose, rose-orange, light beige, blue, red, intensive blue
Class IIa, standard colours: clear, rose, rose-orange, light beige, blue, red, intensive blue
Property
Unit measurement
Result
Hardness
Shore D
> 84
Flexural strength
MPa
> 75
Flexural modulus
MPa
> 1750
Tensile strength
MPa
> 47
Elongation
> 9%
Auflex FAST:
General-purpose ear impression silicone with colour change for visual setting check.
The colour change from blue to white indicates that the setting process is completely finished and the impression can be removed.
Thixotropic, maximum detail reproduction and tear resistance, scanable. Patient-friendly: extra short time in the ear (just 90 sec.!), easy to remove.
“See through” cartridge with visual level control.
A-silicone, biocompatible, medium viscous. Time in the ear: 1:30 min., final hardness: approx. 30 Shore A, Medical device Class I,
Colour: white
3D imrpession material addition cure silicone light body for fine detail
impression material for taking impressions of components
dimensional accurate
fine detail reproduction
smooth consistency
easy mix soft putty.
choice of working time
putty and catalyst in tube
smooth consistency
easy mix soft putty.
choice of working time
putty and catalyst in tub
Property Unit measurement Result
Final Hardness Shore A > 20
DIP
Special dip coat for silicone ear impressions and earmoulds, no annoying skin formation in the dipping bath.
Efficient use in the lab, contains no toluene.
Low viscosity, cold curing, high gloss, transparent, strong adhesion. Medical device Class IIa
use:
direct fabrication of hard acrylic ear moulds .
Properties:
self curing, fast set, hard transparent or irose tint
self curing resin presented in dual syringe with mixing tips
Auflex JUNIOR:
Precision ear impression silicone for children and teenagers (also suitable for small/ narrow auditory canals).
Low viscous, smooth consistency.
No pressure build-up, no displacement of soft tissue.
The material is stable due to its high thixotropy, no unwanted run-off!
The child material is non-sticky and easy to remove.
Extremely tear resistant, highest elastic recovery from deformation (99.8 %), dimensionally stable.
Extra short time in the ear (2 min.!).
Handy minimix cartridges, easy to use. A-silicone, low viscosity, final hardness: approx. 25 Shore A, Medical device Class I,
Colour: yellow
auflex soft putty
General-purpose putty, soft creamy initial consistency, easy mixing and removal, fast set.
Excellent cost/performance ratio, highest detail reproduction and tear strength, well retaining its shape and volume; skin-friendly & biocompatible. A-silicone,
Colour: pink,
Final hardness: approx. 35 Shore A, Medical device Class I,
Scent: melon
