Engineering LCD Series Flex 82A Resin

The Engineering LCD Resin – Flex 82A is a rubber-like resin that combines semi-flexibility with strength and whose material properties are similar to those of TPU. With a Shore hardness of 82A, the resin withstands frequent loads from bending and pressure.

Main Features of Engineering LCD Series Flex 82A – Resin

• Material properties similar to rubber
• Good elasticity against bending and compression
• Excellent material properties in terms of cushioning and shock absorption
• Good compatibility with all SLA, DLP and LCD / MSLA 3D printers in the range of 385 – 420nm

Applications of Engineering LCD Series Flex 82A – Resin

• Custom-fit seals
• Wearables and soft-touch applications
• Mechanical and operational spare parts
• Handles
• Small batch production

Before you start printing

• Shake the bottle for at least 2 minutes before each use
• After shaking the bottle, let the resin sit for 10 minutes to allow air bubbles to escape from the resin.
• Always wear safety glasses and nitrile gloves when handling resin.

Note: The unused resin can be poured back into the bottle after the print is finished.



Post-processing

• The manufacturer recommends post-processing the print in order to achieve the best material properties.
• Rinse your model in IPA or ethanol for about 5 minutes.
• An ultrasonic cleaner is recommended.
• Make sure objects rinsed with IPA and/or ethanol are perfectly dry before further post-curing.
• Place the rinsed parts in a well-ventilated area for at least 30 minutes or use compressed air for at least 2 minutes.
• Cure your object in a high-performance curing chamber for approx. 20-30 minutes at 65 ° C. The preferred curing wavelength is between 300-410 nm.
